Grafix DoubleTack® 2-side adhesive mounting film has twin coatings of permanent adhesive on both sides of an ultra-thin carrier, protected by two sheets of heavy release liners. It bonds instantly to paper, fabric, wood, metal, plastic and glass surfaces. This product is great for applications that require double-sided adhesive, and for creating multi-layered effects.
Double Tack is ready to use without heat or paste, easy to cut, and adheres permanently. Both the film and adhesive are acid-free and archival.
Features
- Durable Duralar polyester film carrier
- Clear adhesive and carrier
- Excellent tear resistance
- Permanent adhesive bond
- Dimensionally stable
- General use adhesive
- No cure time needed
- Easily removable liner
- Supplied in rolls and sheets
Stock
Raw materials
Master Roll (by width)
- DoubleTack is produced in 54″ rolls and is always in stock
- Narrow widths of DoubleTack can be cut to size from 54″ master rolls
Finished Goods
Sheets
- DoubleTack is stocked in sheet sizes: 9″x12″, 18″x24″ and 24″x36″
- Custom sized sheets from 54″x60″ down to 1″x1″ can be produced
Custom sizes and configurations are available with certain minimum quantities ordered.
Specs
Properties are based on standard Archival DoubleTack Film configuration.
| Phyical Properties | |||||||
|---|---|---|---|---|---|---|---|
| Thickness | |||||||
| FaceStock (Clear Duralar) | .001″/25um | +/-5% | ASTM D 3653 | ||||
| Adhesive | .001″/25um | +/-10% | |||||
| Liner, 55# | .0032″/80um | +/-5% | Both Sides | ||||
| PSA Adhesion Properties | |||||||
| Ultimate Peal from | Loop Tack | Shear | Peal | ||||
| Stainless Steel | 2.9 lbs/in | 0.9 | 4.3 lbs/in | ||||
| Usage Characteristics | |||||||
| Application Temp Min. | 35 Deg. F/(1 deg C) | ||||||
| Service Temp | -40 F to 230F/-40C to 120C | ||||||
| Environmental Resistance | |||||||
| Moisture & Humidity | Good | ||||||
| Sunlight & Weather | Not Rated | ||||||
| Heat resistance | Good | ||||||
| PH Value | Neutral | ||||||
| Chemical Resistance | |||||||
| Acids | Excellent | ||||||
| Alkalis | Excellent | ||||||
| Oils | Excellent | ||||||
Duralar facestock properties can be found on the Clear DuraLar product page. For more specific questions regarding DuraLar Film, please contact your sales representitive today!
Important Notice: Grafix makes no warranties, express or implied, including but not limited to any implied warranty of merchantability of fitness for a particular purpose. The user is responsible for determining whether the Grafix product is fit for a particular purpose and suitable for the user’s method of application. Please remember that many factors can affect the use and performance of a Grafix Plastics film product in a particular application. Given the variety of factors that can affect the use and performance of a Grafix product, some of which are uniquely within the user’s knowledge and control, it is essential that the user evaluate the Grafix product to determine whether it is fit for a particular purpose and suitable for the user’s method of application.
Limitation of Remedies and Liability: If the Grafix product is proven to be defective, THE EXCLUSIVE REMEDY, AT GRAFIX’S OPTION, SHALL BE TO REFUND THE PURCHASE PRICE OF OR TO REPAIR OR REPLACE THE DEFECTIVE GRAFIX PRODUCT. Grafix shall not otherwise be liable for loss or damages, whether direct, indirect, special, incidental or consequential, regardless of the legal theory asserted, including, but not limited to, contract, negligence, warranty or strict liability.
Safety
- DEHP, DBP and BBP free. Contact us for more details
- RoHS Compliant. Contact us for more details
Ready to order, or still have questions about our DoubleTack Adhesive Film Products? Use our start an inquiry form to contact us today.
