Adhesive DuraLar™ Polyester Film

Looking to get something quickly? We’ve got you covered with the following Adhesive DuraLar materials in stock and ready to go.

Raw Materials

Master Rolls (by width)

Type	Thickness	20″	27″	40″	50″+
PS – Clear
	.002		•
	.005	•		•	•
PS-Gold
	.002		•
PS-Silver
	.002		•

Finished goods stock sizes:

Sheets

Type	Thickness	20 x 25″	20 x 27″	20 x 50″	24 x 36″	25 x 40″	27 x 40″	30 x 40″
PS – Clear
	.002		•				•
	.005	•		•		•		•
PS-Gold
	.002		•				•
PS-Silver
	.002		•				•

Rolls

Type	Thickness	20″ x 50′	20″ x 100′	27″ x 50′	27″ x 100′	40″ x 50′	40″ x 100′
PS – Clear
	.002			•	•
	.005	•	•			•	•

Packs

Type	Thickenss	8.5 x 11″	9 x 12″	10 x 12″	11 x 14″	14 x 17″	18 x 24″
PS – Clear
	.002			•
	.005	•			•	•
PS-Gold
	.002			•
PS-Silver
	.002			•

Custom gauges and configurations are available with certain minimum quantities ordered.

Properties are based on .005″/125um general use PSA Clear Duralar polyester film. Properties of other gauges and finishes of DuraLar polyester film can vary.

Phyical Properties
	Thickness
		FaceStock (Clear Duralar)		.002″/50um, .005″/125um		+/-5%	ASTM D 3653
		Adhesive		.001″/25um		+/-10%
		Liner, 67#				+/-5%
	PSA Adhesion Properties
		Ultimate Peal from		Loop Tack	Shear		Peal
			Stainless Steel	4.1 lbs	4 hours		4.0 lbs
			HDPE	2.3	na		2.2 lbs
Usage Characteristics
	Application Temp Min.			25 Deg. F/(-4 deg C)
	Service Temp			-40 F to 302F/-40C to 150C
Environmental Resistance
	Moisture & Humidity			Excellent
	Sunlight & Weather			Very Good	Note: Not UV Stablized facestock.
	Heat resistance			Very Good
	PH Value			Neutral
Chemical Resistance
	Acids			Excellent
	Alkalis			Excellent
	Oils			Excellent

Duralar facestock properties can be found on the Clear DuraLar product page.  For more specific questions regarding DuraLar Film, please contact your sales representitive today!
